NFE Series 3 In 1 Hot Juice Filling Lines

NIHIRA NFE Series of machine used in HOT filling ofjuicebeverages with 3 in 1 Rinsing Filling and capping of PET Bottles.

Features

  Air in feed conveyor
  A Easy and smooth in feed star wheel
  We also provide neck held technology for bottles in feed star wheel
  Rinsing is completely stainless steel, robust and durable
  It won't touch screw part of bottle which minimises contaminating
  Direct connection between pasteuriser and mono block, complete wash down system and CIP can be connected directly   to machine.
  Filler having special nozzles for accurate filling
  Caps are fed by caps elevator which gives uninterrupted capping operation
  Special and long lasting magnetic tool is used to provide equal torque and easy settling

---

Specifications

Model	NFE-16-12-6	NFE-18-18-6	NFE-24-24-8
Capacity Ref. 500 ml BPH	4000	6000	8000
Washing Head	16	18	24
Filling Head	12	18	24
Capping Head	6	6	8
Bottle Size	50-60 mm 150-300 mm ht	50-60 mm 150-300 mm ht	50-60 mm 150-300 mm ht
Power KW	3.5	4	5.6
Dimensions	2350x1700x2300	2500x1900x2300	4200x2300x2300
Weight	2500 KG	3000 KG	4000 KG
